JKS500F CRAWLER-MOUNTED REVERSE CIRCUL ATION DRILL RIG

Well Drilling Equipment Features

JKS500F reverse circulation drill rigs are suitable for the construction of complex' foundation projects such as pebbles, cemented pebbles and rock sockets, and arewidely used in geological exploration and sampling, bridge bored piles, and under-ground diaphragm wall foundation projects.

RC drilling uses high-pressure air to drive a pneumatic hammer and return cuttings through an inner tube. This method provides continuous sample recovery at 3x the speed of core drilling while maintaining sample integrity for accurate assay results.

Well Drilling Equipment Parameters

JKS500F Technical Specifications & Performance Data.

We supply matched compressor packages or integrate with your existing fleet.

Key Advantages

The telescopic mast can extend to handle 6m casing pipes in ODEX dilling,and retract to increase stability in conventional dillig. It saves the slidingrail, and features compact transport dimension, light weight and less trans-port cost, etc.

The concentrated control panel includes various controls, which are easy,stable and fficient, like the fast lift and feed can reduce auxillary time and im-prove working fficiency, and the adjustable dilling pressure can well adapt to diferent hole depths.

The strong rotating torque, with an output of 9000Nm, can deal with uncon-solidated rock formation very well and improve dilling eficiency.

The long-stroke leveling legs enhance the working stability of the drill rig, andenable it to be transferred with no need of crane.

The 132Kw engine drives the large-displacement plunger pump, excels in highpower and stable performance.

Get JKS500F Quote & Delivery Schedule

Why choose JKS500F?

High-Quality Sampling: Designed specifically for reverse circulation, ensuring samples are brought to the surface through the inner tube without contamination from the borehole wall. Perfect for accurate geological analysis.

Powerful Penetration: Equipped with a high-torque rotary head and optimized for Down-The-Hole (DTH) hammers, providing fast penetration rates in hard rock and fractured formations.

Integrated Dust Suppression: Features a cyclone dust collector system to minimize environmental impact and ensure operator safety on site.

Superior Mobility: The heavy-duty crawler chassis allows for easy maneuvering across rugged mining terrains and steep slopes.

Applications

Mineral Exploration (Gold, Copper, Iron Ore, etc.)

Grade Control Drilling

Geotechnical Investigation

Water Well Drilling (RC Method)

Foundation Engineering

Contact our mining solutions team for commodity-specific case studies and client reference calls.

Planning an exploration program or need to upgrade your grade control drilling? Our mining equipment specialists will analyze your project requirements (depth, formation, commodity, budget) and recommend the optimal rig configuration.Get JKS500F Quote & Delivery Schedule.
